T5 value – SHARKOON T5 Economy User Manual
Page 14
T5 VALUE
14
5. Connect the 3.5" device to the power supply and the mainboard.
6. Screw the 5.25" bezel with 3.5" opening into the front panel (fig. 20) and place it back onto
the case.
5.25" bezel with 3.5" opening
fig. 20
9. Installation of an add-on card
1. Remove the slot bezel’s fixation screw and take away the slot bezel (fig. 21).
fig. 21
