REBEL9 PRO
9. Installation of an add-on card
1. Remove the slot bezel’s fixation screw and take away the slot bezel (fig. 21).
fig. 21
2. Insert the add-on card into the mainboard’s respective slot and fix it to the case by
re-attaching the fixation screw (fig. 22).
fig. 22
10. The pre-installed fans (only Value)
1. The pre-installed 120 mm fans provide a 4-pin PSU connector and a 3-pin mainboard plug
each.
2. Connect one of both plugs to either the respective PSU or (to control the fan speed via the
mainboard) the matching mainboard connector.
