6
required for those appliances.
For 38204 , with modified sine wave output, some appliances like speed controllers found in some
fans, power tools and some power tools’ AC charger may not like the modified sine wave
generated by the inverter, those appliances may not work or may be damaged if they are
connected to the inverter. If you are unsure about powering any device with the inverter, contact
the manufacturer of the device.
Estimate Run time on Load
Following run time is an estimate based on using a 12V-120AH battery bank for reference. Actual
run time may vary.
Load Consumption Estimate Run time
Cordless Phone 5W 150 hrs
Clock/Radio 8W 100 hrs
Table Lamp 40W/60W 27 hrs/ 18 hrs
Freezer (8.8 cu. ft.) 80W 15 hrs
20” LCD TV 100W 11.5 hrs
Sump Pump (1/2 hp) 350W Not applicable (surge too high)
5. TROUBLESHOOTING
To trouble shoot the unit, please note the error code display on the main unit and review the
“Understanding the Error Codes” in section 4.
Problem Symptom Solution
No AC output and
‘Power’ indicator is off.
The unit is off Turn unit ON using the toggle switch
No power to inverter Check fuse or the Disconnect switch (if
installed) is either blown or turn OFF
No AC output. ‘Fault’
indicator is ON
Unit detect fault and has
shutdown
Verify the error condition and make correction
and reset unit
Products connected to
unit malfunction or
overheat (38204 )
Products connected to unit do
not accept modified sine wave
output generated by the
inverter
Products are not compatible with the modified
sine wave output generated by inverter. See
“AC Load on Power Inverter” in Section 4. Use
NATURE POWER Inverter with sine wave
output
No AC output. ‘Power’
indicator is ON (38304
only )
GFCI was tripped Check load. Reset the GFCI by pressing the
reset button on the GFCI
6. SPECIFICATIONS
Note: Specifications are subject to change without notices.
Specification 38304 38204
Inverter
AC Output Power 400W
AC Output Current 3.3A 3.3A
AC Surge Power (Peak) 800W
AC Output Voltage 120Vac
60Hz
120Vac
60Hz
AC Output Waveform True Sine Wave
(<3%THD)
Modified Sine Wave
Nominal DC Input Voltage 12.5 VDC
No Load battery draw < 0.8 ADC < 0.3 ADC
DC Input Voltage operating range 10.5 – 15.5 VDC
Under Voltage Alarm 11.2 VDC
Under Voltage Shutdown 10.5 VDC
Under Voltage Recovery 11.8 VDC
Over Voltage Shutdown 15.5 VDC
