5
* Wireless remote control is an optional accessory.
If your fan comes without a wireless remote, the LED indicator will not flash when the fan is
powered on. Also, turning DIP switch no. 10 to “ON” will not work either.
3. DMX Control:
The machine uses one DMX channel for adjusting the fan speed.
DMX setting:
DMX value Function
0~10 fan off
11~92 low speed
93~174 medium speed
175~255 high speed
DMX control will override both manual and wireless control functions.
DMX addressing by DIP switches:
DIP 1 2 3 4 5 6 7 8 9 10
Ch. 1 2 4 8 16 32 64 128 256 Wireless control
on/off
- Technical Specifications
Model AF-5
Power supply AC 100~120 V, 50/60 Hz or AC 220~240 V, 50/60 Hz
Horsepower 1 HP
Dimensions (LxWxH) 530 x 470 x 490 mm
Vent dimensions 454 x 153 mm
Weight 17.5 kg
*Please read and save these instructions*
