Kushlan Products KPT 36/48 - Manual (Page 13)

Item Part No. Part name Qty
1 36601 Clutch-ring 4
2 36602 Spring 1
3 36603 Cover 1
4 36604 Screw M8×16 2
5 36605 Bushing 1
6 36606 Spacer 1
7 36607 Gasket 8 1
8 36608 Bolt 5/16”×40 1
9 36609 Friction Wheel A 1
10 36610 Lubrication bearing 1
11 36611 Bearing 1
12 36612 Friction Wheel A 1
Spider Plate Part List
Item Part No. Part name Qty
1 36501 Spider plate 1
2 36502 O-ring 30×2.4 4
3 36503 Nut M8 4
4 36504 Carriage bolt 4
5 36505 Lift lever 4
6 36506 Bolt M8×16 4
7 36507 Trowel arm 4
8 36508 Bolt M8×40 4
9 36509 Bolt M8×50 4
10 36510 Gasket 8 8
11 36511 Bushing 4
12 36512 Trowel blade assembly 4
13 36513 Grease fitting M8x1 4
14 36514 Retainer 1
15 36515 Screw M12×25 1
16 36516 Cap plug 1
17 36517 Pressure plate cap 1
18 36518 Bearing 51209 1
19 36519 Bushing 1
20 36520 Pressure plate 1
6 Clutch assembly
13
Clutch Part List
