The Wireless Connectivity Expert
IR210L IrDA Motherboard Adaptor
User’s Manual
Page
12
of
14
Feb. 14, 2006
Ver. 1.5.1
11)
SPECIFICATIONS
Model : ACT-IR210L+
Carrier :
Infrared radiation (peak wavelength: 850 to 1050nm)
Communication Distance:
From 0 cm to 250 cm.
For best results, from10 cm (3.95 in) to 150 cm (4 ft. 11.05 in)
IrDA-IR:
Baudrate : 9.6,19.2,57.6,115.2K bps
Parity Bit : None
Data : 8
bit
Stop Bit
:
1 bit
Error Check : CRC
Connector :
5-pins connector to motherboard
Power Source :
Motherboard
Power Consumption :
0.30mW (11mA max.)
Operating temperature:
0
o
C to 40
o
C (32
o
F to 104
o
F)
Dimensions (Inches) :
2.0”L x 1.63”W x 0.62”H (51mm x 41mm x 16mm)
Weight :
2.0 oz (54 gr.)
Accessories : User
Manual
Pin Assignments:
5-PIN CONNECTOR
Pin Color
Symbol I/O Function
1
Red
VCC
O
+5V Power Supply
2 Blue
NC - Non
Connected
3 Yellow
IRRX I IR
Receive
4
Black
GND
-
Reference ground (0V) for all signals
5 Green
IRTX O IR
Send
5 pins to 6 pins changer
1 2
Pin P1
P2
1 VCC
NC
2 NC
NC
3 IRRX
GND
4 GND
VCC
5 IRTX
IRRX
6
IRTX
5 6
