2 ©2010 Johnson Level & Tool - Rev. 1
Table of Contents
1. Kit Contents
2. Features and Functions
3. Safety Instructions
4. Location/Content
of Warning Labels
5. Location of Parts/Components
6. Operating Instructions
7. Using the Product
8.
Technical Specifications
9. Care and Handling
10. Product Warranty
11. Warranty Registration
12. Accessories
1. Kit Contents
Description Qty.
Tiling/Flooring Laser Level 1
“AA” Alkaline Batteries 2
Floor Target 1
Instruction Manual with Warranty Card 1
Soft-sided Pouch 1
2. Features and Functions
This simple-to-use tool allows you to generate two lines on the
floor at 90º angles for surface layout including tile, stone, brick,
carpet and hardwood flooring. Unlike lines drawn from chalk, the
40-6616 projects two laser beams over wet mastic or concrete.
Angles are easily established with the built-in protractor.
