Location of part/components – Johnson Level & Tool Mfg. 40-6962 User Manual
Page 4
4
©2011 Johnson Level & Tool - Rev. 1
3. Location of Part/Components
Circular bubble vial
observation prism
Circular bubble vial
Adjusting screws for
circular bubble vial
Eyepiece cover
Eyepiece
focusing knob
Horizontal circle
Leveling screw
Horizontal circle
reference mark
Compensator
check button
Optical sight
Base plate
Focusing knob
Objective lens
Horizontal tangent knob
4579H_Manuals 4/4/11 8:37 AM Page 4
