3. Location of Part/Components
Focusing knob
Leveling Vial
Vertical
tangent knob
Eyepiece
Horizontal graduated
circle
Horizontal vernier
Telescope
objective lens
Leveling screw
Vertical arc
Lock Lever
Vertical lock knob
Horizontal
tangent knob
Base
Vertical vernier
