■ chapter 4 upgrading your computer
Installing the Mini-Card into the System
To install a new Mini-card, do the following:
1. Follow steps in the previous section, Installing a memory
module (DIMM) into the system, to access the Mini-Card
Socket underneath the System Device Cover.
2. The mini-card will only fit in one direction. Align the small
notch in the module with the socket on the connector and insert
the card at an angle of approximately 30 degrees into the
empty socket. Then press it firmly so that the contact edge is
driven into the receiving socket. Pivot the mini-card and fasten
2 Screw-F’s to hold the card down.
Note:
If you want to remove the mini-card from the socket, remove 2
Screw-F’s. The card should pop up to an angle of 30 degree.
3. Locate the antenna cable with connector. Snap the cable
onto the golden connector on the wirelss mini-card. (Note: The
4-16
