5
5
1 1
Ports, Buttons, and Connections Ports, Buttons, and Connections
A Headphone jack
B Power On indicator
C Hard Disk activity indicator
D Battery charger indicator
E Stop/Escape/Off
F Navigation Joystick & Play/Enter button (Press down)
G On/Menu
H USB 2.0 port (USB 1.1 compatible) to connect to computer
I Power Connector (Use only the supplied Archos charger)
6
6
2 2 First Time Usage First Time Usage
2.1 Charging the Battery 2.1 Charging the Battery
Before using your Gmini XS202 S for the fi rst time, completely charge the battery for three hours.
• Connect the Gmini™ XS202 S to the provided charger/adapter and a wall outlet. The blue CHG indicator lights
up to indicate that the external adapter is connected. The battery will charge automatically when it is plugged
in. The battery is fully charged when the full battery icon appears.
• After the fi rst initial full charge, you may use the Gmini while the AC adapter is plugged in.
Animated battery: Full battery:
The battery is currently being charged. The battery is fully charged.
