appendix A product specification
A-2
▼ Processor and Core Logic
Mobile Intel Pentium M – Dual-Core Processor
(Yonah), up to 2.16GHz, 2 MB L2 cache or
Mobile Intel Pentium M – Single-Core Processor
(Yonah), up to 1.66GHz, 2MB L2 cache
Intel Calistoga 945PM + ICH7-M chipset with audio,
modem, and USB2.0 controllers integrated
667MHz Front Side Bus
533 / 667MHz DDR2 interface
▼ System Memory
DDR2 SDRAM 533 / 667
256 / 512 / 1024MB
Two 200-pin DIMM sockets, Max 2 GB
▼ Display
17-inch (1440x900) WXGA TFT LCD or
17-inch (1920x1200) WUXGA TFT LCD
ATI M56-P MXMII (with 256MB DDR3 Frame Buffer)
Supports MXM TypeIII
Hardware Motion Compensation and IDCT Supported
for MPEG1/2 Playback
DirectX compatible
Processor
Core Logic
Memory Type
Default
Memory
Expansion
LCD Panel
Graphic
Accelerator
Motion
Playback
Other
Features
