■ chapter 1 getting to know the basics
1-7
Front and Rear View
Warning: Do not place any heavy objects on the top of notebook. This may
damage the display
1. Microphone/Audio Line-in Jack
The microphone/Audio Line-in jack (3.5-mm diameter) is where
you connect a microphone or an external audio input source
such as a CD Player..
2. Stereo Headphone / SPDIF-out Jack
The stereo headphone jack (3.5-mm diameter) is where you
connect the headphones or external speakers. Alternatively,
you may connect the SPDIF output to an external DTS, AC3, or
PCM sound processor / decoder in your home stereo system.
3. Wireless On/Off Button
Press the Switch to disable or enable the Wireless function. If
the WLAN function is enabled, the WLAN LED turns green;
otherwise, the WLAN LED is dark.
