2.7 E NVIRONMENTAL REQUIREMENTS
♦
operating temperature : 0°C / +50°C
♦
storage temperature : -20°C / 70°C
♦
operating humidity : < 80% at +35°C
♦
vibration : 2g sinusoidal, from 10Hz to 100Hz.
3. CONNECTORS AND CABLES
3.1 ‘’D ATA AND SYNC ’’ CONNECTOR
50 points 3M connector.
♦
connector reference :HIROSE DX10A-50S.
♦
mating connector on cable side : HIROSE DX40-50P ; shell : HIROSE DX50-CV1.
Pin-out :
Pin n° Signal Pin n° Signal
1 PCK+ 26 LEN+
2 PCK- 27 LEN-
3 FEN+ 28 COLOUR_O1+ (1)
4 FEN- 29 COLOUR_O1-(1)
5 COLOUR_O2+ (1) 30 GROUND
6 COLOUR_O2-(1) 31 GROUND
7 PDATA0+ 32 PDATA1+
8 PDATA0- 33 PDATA1-
9 PDATA2+ 34 PDATA3+
10 PDATA2- 35 PDATA3-
11 PDATA4+ 36 PDATA5+
12 PDATA4- 37 PDATA5-
13 PDATA6+ 38 PDATA7+
14 PDATA6- 39 PDATA7-
15 PDATA8+ 40 PDATA9+
16 PDATA8- 41 PDATA9-
17 PDATA10+ 42 PDATA11+
18 PDATA10- 43 PDATA11-
19 GROUND 44 NC
20 GROUND 45 NC
21 SHUTTER+ 46 TRIG_ITC+
22 SHUTTER- 47 TRIG_ITC-
23 COLOUR_I1+(1) 48 COLOUR_I2+(1)
24 COLOUR_I1-(1) 49 COLOUR_I2-(1)
25 NC 50 NC
Notes :
◊
NC : not connected.
◊
(1) : grey cells : not used for CAMELIA COLOR : must be left unconnected
◊
a "Data + Sync" cable is provided with FGT Frame grabber, including a part to be connected to the
electro-optical interface, and the second one to the "FGT" frame grabber : see "FGT Frame Grabber user
manual".
