Installation Instructions 69-3488
3
Revised Feb-2014
Raise the vehicle and support the frame with jack stands. Remove the wheels and tires.
Remove the front plastic debris plate.
The Bill of Materials represents the component contents of this kit. All hardware is of the highest grade
and the components are manufactured to exacting specifications for a trouble free installation. Use the
attached torque specifications chart when final tightening of the nut and bolts are done.
Bill of Materials
Disconnect the ABS sensor at the frame. 4.
2. 1.
3.
Description Qty
M12‐1.25 Stover Nut 4
M12 Washers 8
Front Differential Skid Plate 1
3" Block and U‐bolt Kit 1
Rear Shock Extension 2
M14‐2.0 x 75mm Hex Head Bolt 10.9 2
M14‐2.0 C‐Lock Nut 2
M14 Washers 4
8" Zip Ties 4
M6‐1.25x20mm Skid Plate Bolt 1
M6‐1.25 Nut 1
Skid Plate Washer Large OD 7mm ID 2
Description Qty
Tubular Upper Control Arms 2
M6 Flat Washer (UCA) 2
M6 Nyloc Nut (UCA) 2
UCA Bushing Kit w/Washer & Grease 1
Aluminum Upper Spacer 2
Aluminum Lower Spacer 2
M10‐1.50x60mm 10.9 Hex Head Bolt 4
M10 Flat Washer 8
M10‐1.50 Stover Nut 4
Diff Drop Spacer Front .955" Tall 2
Diff Drop Spacer Rear .750" Tall 2
M12‐1.25 x 120mm 4
