Installation Instructions 66-5912
3
The Bill of Materials represents the component contents of this kit. All hardware is of the
highest grade and the components are manufactured to exacting specifications for a
trouble free installation. Use the attached torque specifications chart when final tighten‐
ing of the nut and bolts are done.
Bill of Materials
Description Qty
Front Strut Extension 2
M10 Flange Nuts 6
Front Diff Drop Kit (Packaged) 1
Description Qty
Skid Plate Spacer Kit (Packaged) 1
Front Sway Bar Drop Spacers 2
M10‐1.25 x 20mm Bolt w/washer 4
1. Remove the skid plate by unbolting the four 12mm
bolts that hold it on.
2. Starting from the passenger side, loosen the upper
and lower strut mount nuts.
3. Loosen, don’t remove the 19mm lower control arm
nut and bolt, Remove the 19mm lower ball joint bolts.
4. Remove the lower strut mount nut and bolt. Push the
lower control arm down.
Lower Ball joint
