SABINE FBX-SOLO SL820 - Manual

FBX-SOLO Model SM820
FBX-SOLO Model SL820
Q
UICK
S
TART
O
PERATION
For best results, read all operating instructions
before using the FBX-SOLO (pages 10-19).
Patch in the SOLO where appropriate for your
model, and select the input/output level on the
back.
Adjust the Clip Level on the SOLO so at least
1 or 2 input LEDs light with your program input.
With gain down on the mixer input channel, put
the SOLO in Active mode (green bypass
LED), then slowly raise the channel gain to the
point of feedback.
Continue raising the gain slowly until 7 FBX
filters are set, then reduce gain slightly.
OPERATING
GUIDE
© 2006 Sabine, Inc.
T
ABLE OF
C
ONTENTS
• Front Panel Descriptions 5
• Back Panel Descriptions 6
• Applications for Use 8
• Before you Begin... 10
• Operating Instructions 13
• FBX Setup Instructions 14
• Trouble Shooting Tips 18
• Product Specifications 20
• Warranty & Cautions 22
1
2
3
4
