Setting up and Recording
4.2
Connect Your Music Creation Suite
Music Creation Suite
Quick Start Guide
4.2
Connect Your Music Creation Suite
Connect your microphone and headphones to the AudioBox USB and
connect the AudioBox USB and PS49 to a computer, with or without
the USB hub. Use the diagrams below as connection guides.
Note: Some laptop computers will not provide enough power from their
onboard USB ports to properly power both the AudioBox USB and the PS49.
If you are having any connection issues, try using the powered USB hub.
Music Creation Suite (no USB hub)
Mic•Instrument
1
2
Power
Clip
Clip
1
11
48V
PLAYBACK
INPUTS
AUDIOBOX USB
0
60
-10
+30
0
60
-10
+30
-80
10
Designed by
PreSonus in
the USA.
Manufactured
in PRC.
R
L
IN
OUT
PHONES
MIDI
USB
HD3 Headphones
M7 mic
computer
M7
