0 F R12 R134a
30 42 40
32 44 42
34 46 44
36 48 46
38 50 49
40 52 51
42 54 54
44 57 56
46 59 59
48 61 61
50 64 64
52 66 67
54 69 70
56 72 72
58 74 76
60 77 78
62 80 82
64 83 85
66 85 88
68 88 92
70 92 95
72 95 97
74 98 104
76 102 107
78 105 110
80 108 114
82 112 118
84 115 123
86 118 127
88 123 130
90 127 135
92 130 140
94 135 145
96 138 148
98 143 153
100 147 157
102 150 163
104 155 167
106 160 173
108 165 180
110 168 185
112 173 190
114 178 195
116 183 200
118 188 207
120 193 213
Purge Chart
5. Determine the room temperature. A Pocket
Thermometer is convenient for this
measurement.
6. Locate the pressure (PSIG) corresponding to this
room temperature (
0 F) in Table at right.
If Pressure Gauge indicates higher than that
determined from the table...
SLIGHTLY & SLOWLY open Valve on
Yellow Service Hose connected to INLET of
TX600 until the Pressure Gauge pressure equals
that shown in the table. Any Non-condensable
Gas will be vented through the Oil Drain Valve.
NOTE...
A copy of the Temperature/Pressure Table is
located on the rear of the TX600 for easy
reference.
7. Close the Oil Drain Valve.
8. Open Valve on Yellow Service Hose connected to
the INLET of TX600 for approximately 5 seconds;
then close. This permits any residual Non-
condensable Gas to be recirculated for reprocessing
during the next recycle procedure.
9. Close VAPOR Valve on Refrigerant Cylinder.
Non-condensable Gas has now been removed and the
refrigerant is ready for charging back into an A/C
System.
CAUTION...
The preceding Recycling and Purge Procedures allow
the Yellow Service Hoses to remain permanently
connected to the TX600. Disconnecting either hose
from the TX600 may vent refrigerant unnecessarily or
introduce air into the system and should be avoided.
The Yellow Service Hoses should remain connected to
the TX600 unless repair or transport is required.
