SpecificATiOn MYDATA SMD TOWeR 513
SOfTWARe funcTiOn
STAnDARD MODe MYlAbel MODe
2) nitrogen possible on request.
cASSeTTeS AvAilAble
Reel WiDTh Reel DiAMeTeRS
4” - 7“ 13“
8 mm • •
12 mm • •
16 mm • •
24 mm • •
32 mm 1) •
44 mm •
1) 32 mm cassettes can alternatively house tray boxes.
1 Tray box = 3 Trays (JeDec)
Max. tray capacity = 504
Reel sizes 8 to 24 mm (4” / 100 mm reels)
8 to 24 mm (7” / 180 mm reels)
8 to 44 mm (13” / 330 mm reels)
freely configurable and expandable
Access time 13 seconds
RAnDOM AcceSS STORAge SYSTeM fOR SMD ReelS
cApAbiliTY
cASSeTTeS
component management • *
Stock monitoring • *
external communication protocol • •
user Access System • •
Traceability • •
Job preparation • *
barcoding • *
Data import / export function • *
inventory function • *
component allocation •
MYlabel integration •
* handled by MYlabel / MYplan software.
SOfTWARe
STAnDARD cOnfiguRATiOn
Reel WiDTh cASSeTTeS / SMD TOWeR ReelS / cASSeTTe nO Of ReelS TOTAl
8 mm / 4” - 7“ 1 14 14
299
8 mm / 13“ 5 14 70
12 mm / 4” - 7“ 2 12 24
12 mm / 13“ 5 12 60
16 mm / 4” - 7“ 1 10 10
16 mm / 13“ 5 10 50
24 mm / 4” - 7“ 1 8 8
24 mm / 13“ 4 8 32
32 mm / 13“ 3 7 21
44 mm / 13“ 2 5 10
MAxiMuM Reel cApAciTY
Reel WiDTh cASSeTTeS / SMD TOWeR ReelS / cASSeTTe nO Of ReelS TOTAl
8 mm / 4” - 7“ 5 14 70
406
8 mm / 13“ 24 14 336
MAxiMuM TRAY cApAciTY
cASSeTTe WiDTh cASSeTTeS / SMD TOWeR TRAY bOxeS / cASSeTTe nO Of TRAY bOxeS TOTAl
32 mm / 13“ 24 7 168 504
cASSeTTe cApAciTY
cASSeTTe TYpe nuMbeR
4” - 7“ 5
13“ 24
cApAciTY
DRY AiR uniT 2000 SupeRpluS Dl25 2)
flow rate, max (in) 25 m 3 /h, (out) 19.75 m 3 /h
flow rate, typ. 3 m 3 /h
Air supply class 4 (iSO 8573-1) or better
Operating overpressure (in) 6 - 16 bar
Medium temperature (in) 5 - 50°c
power supply 110 / 230 v, 50/60 hz, 7W
Dimension (W x D x h) 121 mm x 300 mm x 1377 mm (4,8“ x 11,8“ x 54,2“)
AcceSSORY
