Pfister RT6-5MXK User Manual
Page 4
6
5
FOR 806 MODELS ONLY
HOLD HANDLE BEFORE
TURNING HUB CLOCKWISE
SPOUT INSTALLATION
INSTALACIÓN DEL CONDUCTO
INSTALLATION DE BEC
HANDLE INSTALLATION
INSTALACIÓN DE LA MANIJA
INSTALLATION DE LA POIGNÉE
Be sure Spout (A) is secured
in place.
Esté seguro que el conducto (A) esté
asegurado en su lugar.
Assurez que le bec (A) soit assuré à sa place.
4
A
A
H
k
B
J
L
M
G
C
D
C
B
