4a 4b – Pfister R89-7WEK User Manual
Page 4
4
4A
4B
4
3
7
⁄
8
" – 4" (98 mm – 101 mm)
F
E
G
Hex Wrench
Llave hexagonal
Clé hexagonale
Teflon Tape
Cinta de teflón
Ruban en téflon
Connect Shower Arm & Spout
Conecte el brazo de la ducha y el surtidor
Branchez le bras de douche & le bec
G
F
E
Use Hex Wrench to tighten set screw beneath E.
Utilice una llave hexagonal para apretar los tornillos de
fijación debajo de E.
Utilisez une clé hexagonale pour serrer la vis sous E.
