AMT Datasouth M2 Series User Manual

Page 2

Printer Model

Resolution

203 DPI

Printing Method

Direct Thermal

Print Speed

Up to 3.5 ips

Max Print Width

2.83” (72mm)

Max Print Length

40” (1016mm)

Enclosure

Double-walled plastic with rubber over
molded enclosure

Physical Dimension 7.23” (L) x 5.1” (W) x 3.54” (H)

183.7mm (L) x 129mm (W) x 90mm (H)

Weight

2.05 lbs (930g) (including battery)

Label Roll Capacity 2.5” (63.5mm) OD

Processor

32-bit RISC CPU

Memory

4MB Flash memory
2MB DRAM

Interface

RS-232 (max 115,200 bps), USB 1.1

Power

Two-cell, 7.4V DC, 2200mAh Li-ion
rechargeable battery

User Interface

Graphical LCD display (122 dots x 32 dots)
with back light

Operation Switch

5 buttons (On/Off, feed, and three context-

Button

sensitive keys)

Sensors

Gap transmissive sensor
Black mark reflective sensor
Head Open
Peeler Sensor

Internal Font

San Serif and OCRB styles with smooth
scaling

Bar Code

Linear barcodes
Code 39, Code 93, Code128 subsets A.B.C.,
Codabar, Interleave 2 of 5, EAN-8, EAN-13,
UPC-A,UPC-E, MSI PLESSEY, POSTNET,
RSS

2D bar code
PDF-417, Maxicode, DataMatrix

Font & Barcode
Rotation

0, 90, 180, 270 degrees

Command Set

PAL

Media Type

Continuous, die-cut, fan-fold, black mark, tag

Media Size

Min width 1.00” (25.4mm)
Max width 3.15” (80.00mm)
Min length 0.75” (19.05mm)
Min length (Peeler Mode) 0.75” (19.05mm)
Max length (Peeler Mode) 6.00” (152.40mm)
Min width (Peeler Mode) 1.00” (25.4mm)
Max width (Peeler Mode) 2.99” (76.0mm)
Min thickness 2.3 mil (0.06mm)
Max thickness 7.4 mil (0.19mm)
Max roll capacity 2.5” OD
Core size 1.0” ID

Environmental

Operation: 32-104°F (0-40°C), 5-90% non-
condensing
Storage: -40-140°F (-40-60°C), 10-90% non-
condensing

Regulatory

FCC, CE, C-Tick Class B, UL, CUL, TUV/GS, CCC

Accessories

Quick start guide, Li-ion battery, 3” width
paper core, hand strap, battery charger
station & power adapter, CD with manual and
windows drivers, cleaning pen, USB cable

Reliability

TPH: 1 million inches or 12 months whichever
comes first

Model Option

Wireless network

User Options

Bluetooth module, shoulder strap

www.amtdatasouth.com

PRINTER SPECIFICATIONS INCLUDE:

Specifications are subject to change without notice.

Part No.121545 rev. A

#8642

All M2s are ready for loading custom PAL applications

as needed for almost any situation or host.
