Technical specifications
General
Power Requirements
115V or 230V AC, set by voltage selector switch on rear panel
Power consumption <30W
Dimensions 430mm x 90mm x 280mm
Weight net: 4.9kg; packed: 6.5kg
Video outputs
Composite video
1 x gold plated phono. 1V pk-pk in 75Ω
S-Video 1 x 4-pin mini-DIN. Y 1V pk-pk in 75Ω, C 0.3V pk-pk in 75Ω
Component video Interlaced or Progressive (525P). 3 x gold plated phono sockets.
Y 1V pk-pk in 75Ω, Pb 0.7V pk-pk in 75Ω, Pr 0.7V pk-pk in 75Ω.
SCART socket with RGB video All 0.7V in 75Ω, composite video 1V in 75Ω, and stereo audio.
Auto switching of TV with aspect ratio control
Audio outputs
Analogue audio outputs
6 channel outputs on gold plated phono sockets
Output level 2.2V rms at 0dB signal, 4V rms on left and right with HDCD discs
Frequency response 20Hz to 20kHz (+0.1db, –0.5dB)
THD+N <0.005% for 1kHz 0dB signal, measured 22Hz–22kHz, unweighted
Signal-to-noise ratio 105dB, measured 20Hz–20kHz, unweighted
Digital audio output (IEC958) PCM/Dolby digital/MPEG/DTS on gold plated phono (coax) and TOSLINK (optical)
Accessories supplied
CR-314 remote control
2 x AAA batteries
mains lead
E&EO
Continual improvement policy
Arcam has a policy of continual improvement for its products.
This means that designs and specifications are subject to
change without notice.
NOTE: All specification values are typical unless otherwise
stated.
