6
Easy-to-Use Panel Design
1 IF output (BNC type)
2 Reference input/output (BNC type)
3 Power
4 AC input
5 Ethernet interface (10BASE-T, optional)
6 RS-232C interface
7 VGA output
8 GPIB interface
9 Parallel interface (D-sub25)
10 Trigger input (BNC type)
11 Video signal output (BNC type)
1
6.5 inch (17 cm)
color TFT-LCD
Memory card slot
Power
Preset
Copy
2
3
4
5 7 9
6 8
10 11
