Port Valve
Valve Model Number
Avg. Dimensions
inches (mm)
Weight
Size Type Green Button Red Button
C
V
A
B
C
lb (kg)
Flush Push Button Actuator
1/8 3/2 1223B1FPG 1223B1FPR
0.6 .1.4 (35) 3.9 (99)
0.8 (21) 0.28 (0.13)
1/4 3/2 1223B2FPG 1223B2FPR
0.9 1.6 (40) 3.9 (99) 1.0 (25) 0.34 (0.15)
Mushroom Button Actuator
1/8 3/2 1223B1MBG 1223B1MBR
0.6 1.4 (35) 4.4 (111) 0.8 (21) 0.29 (0.13)
1/4 3/2 1223B2MBG 1223B2MBR
0.9 1.6 (40) 4.4 (111) 1.0 (25) 0.35 (0.16)
Selector Switch Actuator
Port Valve
Valve Model Number Avg. Dimensions
inches (mm)
Weight
Size Type
Black Switch Knob
C
V
A
B
C
lb (kg)
1/8
3/2
1223B1SLB
0.6
1.4 (35) 4.6 (118) 0.8 (21) 0.31 (0.14)
1/4
3/2
1223B2SLB
0.9
1.6 (40) 4.6 (118) 1.0 (25) 0.37 (0.17)
Manual Valves Series 12
Port Thread 1/8
B
C
A
B
A
C
1.46
(37)
1.26
(32)
1.46
(37)
1.26
(32)
1.26
(32)
0.81 (21)
1.46
(37)
1.06
(27)
ON
OFF
90°
4.4
(111)
4.6
(118)
1.77
(45)
2.13
(54)
1.06
(27)
1.38
(35)
1.30
(33)
3.9
(99)
1.06
(27)
1.18
(30)
1.57 (40)
0.98
(25)
1.02
(26)
0.55
(14)
(4 O-Rings)
4x0.08 (2)=0.3 (8)
0.77
(20)
0.71 (18)
3.1
(79)
0.79
(20)
3-G1/4
VOD (Vaild Operation Distance):
0.22 inches (5.5 mm)
IOD (Invaild Operation Distance):
0.04 inches (1.0 mm)
VOD
IOD
3-o 5.4
1.46
(37)
1.26
(32)
1.77
(45)
2.13
(54)
0.93
(24)
0.70
(18)
0.58
(15)
1.37
(35)
0.98
(25)
3.9
(99)
1.42
(36)
0.23
(6)
0.58
(15)
0.71
(18)
4.6
(118)
3.1
(79)
0.79
(20)
0.82
(21)
4.4
(111)
1.46
(37)
1.26
(32)
1.26
(32)
0.81 (21)
1.46
(37)
1.06
(27)
ON
OFF
90°
1.38
(35)
1.30
(33)
4x0.08 (2)=0.3 (8)
3-G1/8
(4 O-Rings)
VOD (Vaild Operation Distance):
0.22 inches (5.5 mm)
IOD (Invaild Operation Distance):
0.04 inches (1.0 mm)
VOD
IOD
4-o 4.4
Port Thread 1/4
Dimensions –
inches (mm)
For BSPP threads add a “D” prefix to the model number e.g., D1223B1FPG.
