• Model E4 Metallic Food Processing
Composite Repair Parts List
Notes:
1.) (4) V170T o-rings are to be used with metallic fitted seats.
Air Valve Assembly
Item # Qty. Description Part Number
1 - Valve Body Assembly (includes items 2-8) P31-200-NP
2 1 Valve Body P31-201NP
3 2 End Cap P50-300NP
4 2 End Cap Gasket P50-110
5 1 Valve Body Gasket P31-202
6 1 Valve Spool P50-104
7 3 Glyde Ring Assembly P50-104C
8 12 Mounting Screws (8 included on item 1) S100A
Center Section Assembly
Item # Qty. Description Part Number
9 1 Center Block Assembly (Includes item 13 & 14) P31-401NP
10 2 Air Chamber P31-101NP
11 2 Air Chamber Gasket P31-109
12 8 Bolt SP31-404
13 2 Bearing Sleeve P31-403
14 2 Main Shaft O-Ring P24-403
15 1 Pilot Shaft P50-112
16 5 Pilot Spacer P24-106P
17 6 Pilot O-Ring P24-107
18 2 Pilot Ring P50-119
19 2 Pilot Retainer P50-109
20 2 Screw S1001
21 2 Stop Nut P24-108
22 1 Muffler VTM-6
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
Versa-Rugged
PTFE
Two Piece Fusion
23 1 Main Shaft P31-103 P31-102 P31-103
24 2 Main Shaft Stud N/A V221F N/A
25 2 Diaphragm (See Below Material Chart) V163xx V163TF V163F
26 2 Back-Up Diaphragm N/A V163TFB N/A
27 2 Inner Diaphragm Plate V161CNP V161TINP N/A
28 2 Outer Diaphragm Plate SVB161 SV161TO N/A
29 4 Valve Seat (See Below Material Chart) V170xx
30 4 Valve Ball (See Below Material Chart) V171xx
Wet End Assembly
Item # Qty. Description Part Number
31 2 Water Chamber SV165FG
32 2 Discharge Manifold SV166FG
33 1 Suction Manifold SV167FG
34 4 Large Clamp Half SP31-110A
35 4 Large Clamp Bolt SV164C
36 4 Large Clamp Wing Nut FG39C
37 8 Small Clamp Half SV169A
38 8 Small Clamp Bolt SV169B
39 8 Small Clamp Wing Nut FG69C
Elastomer Material Specifications
Material Versa-Rugged Diaphragm P/N "Ball P/N" Seat P/N
PTFE See item # 25 V171TF N/A (use metallic seat)
FDA Hytrel V163TPEFG V171TPEFG V170TPEFG
Stainless Steel N/A V171SS SV170 (See Note 1)
FDA Santoprene V163TPEXLFG V171TPEXLFG V170TPEXLFG
MODEL SPECIFIC
3: EXP
VIEW
