• Model RE2 Plastic Bolted
RE2 Bolted metallic Service Kits
Item
Description
Qty
Part Number
AIR VALVE KIT
E2/E3 A AV KIT
3
Glide Ring
4
P34-204F
5
End Cap Gasket
2
P24-205
9
Valve Gasket
1
P24-202
PILOT VALVE KIT
E3A PV KIT
19
Pilot Shaft Spacer
5
P24-106
20
Pilot Shaft O-Ring
6
P24-107
21
Stop Nut
2
P24-108
34
Main Shaft O-Ring
2
P24-403
ELASTOMER KITS
See Factory
40
Diaphragm
2
50
Valve Seat
4
52
Valve Ball
4
Item Description
Oty Part #
E2 - Comprehensive Maintenance Kit -
OE Speel Valve - Rubber Fitted -
Metallic Bolted
E2 - CMK-OE-
RB-MB
39 SHAFT (RUBBER & XL PUMPS)
1
P24-103
19 PILOT SHAFT/SS
1
P24-104
18 BUSHING, THREADED
2
P24-105
21 O-RING, PILOT VALVE
6
P24-107
22 18.8 JAM NYLON LOCK NUT
2
P24-108
16 CENTER BLOCK GASKET
2
P126-0008
16 CENTER BLOCK GASKET
2
P79-109
9
AIR VALVE GASKET
1
P24-202
5
GASKET/END CAP
2
P24-205
38 BUSHING O-RING
2
P24-403
43 BUMPER WASHER
2
P24-501
3
GLYD RING, 2 PIECE SET
4
P34-204F
37 AIR MUFFLER-2"
1
530.041.000
2
SPOOL, E2/E3, AIR VALVE
1
P126-0063
20 RING, PILOT VALVE
5
P24-106
46 PROBE TIP
2
846.001.167
47 PROBE TIP O-RING
2
560.201.360
E2 - Comprehensive Maintenance Kit -
E2-CMK-OE-
TF-MB
39
OE Speel Valve - Teflon Fitted -
Metallic Bolted
SHAFT FOR TEFLON-FITTED PUMPS
1
P24-102
19 PILOT SHAFT/SS
1
P24-104
18 BUSHING, THREADED
2
P24-105
21 O-RING, PILOT VALVE
6
P24-107
22 18.8 JAM NYLON LOCK NUT
2
P24-108
16 CENTER BLOCK GASKET
2
P126-0008
16 CENTER BLOCK GASKET
2
P79-109
9
AIR VALVE GASKET
1
P24-202
5
GASKET/END CAP
2
P24-205
38 BUSHING O-RING
2
P24-403
43 BUMPER WASHER
2
P24-501
3
GLYD RING, 2 PIECE SET
4
P34-204F
37 AIR MUFFLER-2"
1
530.041.000
2
SPOOL, E2/E3, AIR VALVE
1
P126-0063
20 RING, PILOT VALVE
5
P24-106
46 PROBE TIP
2
846.001.167
47 PROBE TIP O-RING
2
560.201.360
Item Description
Qty Part Number
RE2 Standard Sensor Kit
476.275.000
33
Sensor
1
P126-0035
46
Probe Tips
2
846.001.167
48
Sensor O-ring
2
560.033.360
47
Probe Tip O-rings
2
560.201.360
RE2 Teflon Sensor Kit
475.276.000
33
Sensor
1
P126-0059
46
Probe Tips
2
846.001.167
48
Sensor O-ring
2
560.033.360
47
Probe Tip O-Rings
2
560.201.360
RE2 Control Module Kit ATEX
(Power Gen Airvantage Only)
476.296.000
81
Control Module Assembly ATEX
1
249.021.000
73
Gasket
2
720.071.360
76
Cap Screw
4
171.091.115
80
O-ring
2
560.205.360
88
Switch Cap O-ring
1
560.104.360
83
Switch Cap
1
165.135.330
Poppet Valve Kit ATEX
476.289.000
75
Poppet Valve Assembly ATEX
1
893.104.000
34
O-rings
1
560.011.360
Poppet Valve Assembly Kit ATEX
476.290.000
75
Poppet Valve Assembly ATEX
1
893.104.000
34
O-ring
1
560.011.360
79
Regulator
1
020.069.000
74
Pilot Valve
1
765.004.000
Power Gen Kit ATEX
476.293.000
77
Power Gen Assembly ATEX
1
031.202.000
73
Gasket
1
720.071.360
76
Cap Screw
4
171.091.115
80
O-ring
1
560.200.360
Seal Kit ATEX
476.280.000
34
O-ring
1
560.011.360
73
Gasket
4
720.071.360
80
O-ring
2
560.200.360
Probe Tip Kit
476.283.000
46
Probe Tips
1
846.001.167
47
Probe Tip O-Rings
1
560.201.360
