Composite Repair Parts List - PTFE Fitted
Notes:
1.) The outer diaphragm plate material is to match the water chamber material (cast iron uses SV302B or SVB307)
2.) In addition to the stainless valve setas, (8) orings are needed. (4) SV456TES-1 and (4) SV456TES-2
Air Valve Assembly
Item #
Qty.
Description
Part Number
1
1
Valve Body (includes items 2-11)
031.V003.156
2
1
Valve Body
095.V001.156
3
1
Valve Body Gasket
P24-202
4
1
Valve Sleeve
755.V005.148
5
6
O-ring
560.206.360
6
1
Valve Spool Assembly (Includes items 7)
775.V001.000
7
6
Glyde Ring Assembly
P34-204F
8
1
Air Valve Screen
P24-210
9
2
End Cap Gasket
P24-205
10
2
End Cap
P34-300
11
13
Mounting Screws (8 included on item 1)
S1001
Center Section Assembly
Item #
Qty.
Description
Part Number
12
1
Center Block Assembly (Includes item 13 & 14)
P34-400DC ASY
13
2
Bearing Sleeve
P34-404
14
2
Main Shaft O-Ring
P34-403
15
2
Air Chamber
196.V008.157
16
2
Air Chamber Gasket
P79-109
17
8
Bolt
P24-110
18
1
Pilot Sleeve Assembly (include item 19)
755.V002.000
19
6
O-ring
560.101.358
20
1
Retaining Ring
675.037.080
21
1
Pilot Spool Assembly (Includes item 22)
775.V002.000
22
8
O-ring
560.023.358
23
1
Muffler
530.033.000
Diaphragm Assembly / Elastomers
Item #
Qty.
Description
Part Number
PTFE Two Piece
PTFE Bonded
24
1
Main Shaft
P34-103
25
2
Diaphragm
V305TF-FB
V305TX
26
2
Back-Up Diaphragm
V305TFB
N/A
27
2
Outer Diaphragm Plate
V302TO
28
2
Inner Diaphragm Plate
V302TI
29
2
Bumper Washer
P34-501
30
2
Back-Up Washer
V302E
31
4
Valve Seat (See Below Material Chart)
V456xx
32
4
Valve Ball
V455TF
Wet End Assembly
Item #
Qty.
Description
Part Number
33
2
Water Chamber
V350FB
34
20
Water Chamber Bolt
V387A
35
52
Nut
V387C
36
52
Washer
V387B
37
2
Manifold Tee
V358FB
38
2
Discharge Elbow
V351E-FB
39
2
Suction Elbow
V352E-FB
40
4
Manifold Seal
V258TFS
41
32
Elbow Bolt
V387D
42
1
Discharge Drop in Manifold
518.V002.156
Discharge Drop in Manifold (BSP)
518.V002.156 E
43
1
Suction Drop in Manifold
518.V003.156
Suction Drop in Manifold (BSP)
518.V003.156 E
Elastomer Material Specifications
Material
Seat P/N
Manifold Seat O-Ring P/N
PTFE
V456TF
N/A
Stainless Steel
(not pictured)
SV456
See Note 2
