35 218212-16 Radiant Med Duty - H
36 43813149 Label, Warning Hot Surface (French)
37 8705800 Knob, Medium Duty Unit
38 8632000 Leg, 4" Adjustable, 2000 Lb Cap.
39 24251-00 Pan, Grease 18”
40 21813029 Grate Support
41 3103800 Grill Grate
42 2067300 Regulator, Convertible 3/4 ½ PSIG
43 8861000 Label, Spec
44 8809920 Decal, Improper Installation
45 8832600 Label, Service Hotline
46 8837130 Decal, Operating Instruction
47 8825300 Decal, Leg
48 8822325 Decal, UL Sanitation, NSF Std. 4
49 8837112 Label, Orifice Size
50 8837190 Tag, Orifice Location
51 43813103 Label, Warning, Hot Surface
52* 2300100 Bags, Poly 36 x 27 x 44
53* 8824618 Decal, Front Panel
54* 2901251 Carton, RSC
55* 29012-35 Pad Accessory
56* 2901255 Post Corner
57* 8837201 Bag, Cloth, 4" x 6" w/Drawstring
58* 8838700 Manual, GCB-H/GCRB-H
59* 2900851 Skid, 21.75 X 29.5
60* 2901240 Pad
61* 8837400 Box Label, APW/Wyott
62* 3100001 Lava Rocks, 8lb Bag
63* 2901231 Carton, RSC
64* 2300000 29 x 19 x 44 Poly
65* 8899300 List Of Service Agencies
66 3102205 Grate, Rock
67 218207-26 Guard, Burner
GCB/GCRB/GGM-18
28.25 X 20.62 X 17, 275lbs
Champion II
23-7/16 X 16-1/16 X 4 275DW
* = Not Shown
1 218207-55 Weldment, 18" Bullnose
2 218215-11 Body, 18" Firebox GGM
3 8431300 1/4-20 Flanged Hex Locknut
4 21813085 Spacer
5 218207-18 Baffle, 18" Front Heat
6 8417100 Nut, Hex, KEPS 10-32
7 218207-23 Support, Leg 18" GCRB
8 218215-13 Bracket, Manifold
9 8153100 #8-32 X 3/8 Type T
10 21820715 Manifold, 18" GCRB
11 2068200 Valve, Gas, On-Off
12 2066828 Orifice #28
13 2066841 Hood, Orifice #41
14 2092517 Plug, 1/8 NPTM
15 2065643 Valve, 90° Pilot 1/8" NPT X 3/16
16 218207-28 Tube, Pilot
17 218207-29 Bracket, Pilot GCRB/GCB/GGM-18
18 2066154 Pilot, Top
19 218207-16 Side, Grease Chute
20 21813313 Side Panel, LH & RH
21 8170700 Screw, 10-32x1/2, Type AB
22 30047501 Guide, Grease Slide
23 218207-57 Panel, Back
24 218207-17 Support, Burner
25 81546-00 #8 X 3/8
26 218130-75 Burner "S”
27 31007-12 U-Nut C7685 10A Tinnerman
28 218207-24 Baffle, Front Panel 18”
29 218207-19 Panel, Control Opt. 4
30 81973-00 T/S #10 X 1/2 TPB Tr Hd
31 218208-26 Cap, End Control Panel R.H.
32 21820827 Cap, End L.H.
33 218207-53 Support, 18" Rock Grate, Rear
34 218207-22 Support, 18" Rock Grate, Front
GCRB/GCB/GGM-18
Item P/N Description Quan Item P/N Description Quan
1
1
6
4
1
6
2
1
11
1
1
1
1
1
1
1
1
1
2
2
12
2
1
2
4
1
4
1
1
4
1
1
1
1
2
1
1
4
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
1
2
1
1
3
1
PARTS LIST: GCB-18H & GCRB-18H
12
