• Model E40 Metallic
Composite Repair Parts List - PTFE Fitted
Notes:
1.) The metallic seat material is to match the water chamber material. In addition to this seat, (8) O-Rings are needed.(Ref Note 2)
2.) These (8) O-Rings are only used with metallic fitted seats. The O-Ring material is to match the diaphragm material.
3.) The inner diaphragm plate is to match the inner chamber material (Ref. Note 4)
4.) V = Aluminum, TC = PTFE Coated, NP = Nickel Plated, SV = Stainless Steel
5.) For Pumps with Stainless center pumps, increase quantity to 4
Air Valve Assembly
Item # Qty. Description
Part Number
Aluminum Stainless Steel Nickle Plated PTFE Coated
1 1 Valve Body (includes items 2-11) 031.V001.156 031.V001.110 031.V001.332 031.V001.309
2 1 Valve Body 095.V001.156 095.V001.110 095.V001.332 095.V001.309
3 1 Valve Body Gasket P24-202
4 1 Valve Sleeve 755.V001.148
5 6 O-ring 560.206.360
6 1 Valve Spool Assembly (Includes items 7) 775.V001.000
7 6 Glyde Ring Assembly P34-204F
8 1 Air Valve Screen P24-210 P34-210 P24-210
9 2 End Cap Gasket P24-205
10 2 End Cap P34-300 SP34-300 P34-300TC
11 13 Mounting Screws S1001
Center Section Assembly
Item # Qty. Description Part Number
Aluminum Stainless Steel Nickle Plated PTFE Coated
12 1 Center Block Assembly (Includes item 13 & 14) P24-400DC ASY SP24-400 P24-401NP P24-401TC
13 2 Bearing Sleeve P31-403
14 2 Main Shaft O-Ring P24-403
15 2 Air Chamber 196.V003.156 196.V003.110 196.V003.332 196.V003.309
16 2 Air Chamber Gasket 360.V001.465
17 8 Bolt P24-110 SP24-110
18 1 Pilot Sleeve Assembly (include items 19 & 20) 755.V002.000
19 6 O-ring 560.101.358
20 1 Retaining Ring 675.037.080
21 1 Pilot Spool Assembly (Includes item 22) 775.V002.000
22 8 O-ring 560.023.358
23 1 Muffler Elbow P126-0072
24 1 Muffler 530.033.000
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
PTFE 2 Piece Fusion
Aluminum Cast Iron Stainless Aluminum Cast Iron Stainless
25 1 Main Shaft P24-102 P24-103F
26 2 Diaphragm V227TF V227F
27 2 Back Up Diaphragm V227TFB N/A
28 2 Inner Diaphragm Plate (See Note 3) V221TI, V221TINP, V221TINP, SV221TI* (See note 5) N/A
29 2* Bumper Washer P24-501* (See note 5)
30 2 Outer Diaphragm Plate SVB226 N/A
31 4 Valve Seat (See Below Material Chart) 722.091.xxx
32 8 Valve Seat O-Ring (See Below Material Chart) (See Note 2)
33 4 Valve Ball (See Below Material Chart) 050.005.xxx
Wet End Assembly
Item # Qty. Description Part Number
Aluminum Cast Iron Stainless
34 2 Water Chamber 196.V001.156 196.V001.010 196.V001.110
35 20 Water Chamber Bolt 170.069.330 170.069.115
36 16 Manifold Bolt 170.085.330 170.085.115
37 36 Washer 901.038.330 901.038.115
38 36 Nut V185B SV185B
39 1 Discharge Manifold 518.V008.156 518.V008.010 518.V008.110
40 1 Suction Manifold 518.V009.156 518.V009.010 518.V009.110
Elastomer Material Specifications
Material "Versa-Dome Diaphragm P/N" "Ball P/N" Seat P/N
"Seat O-ring
(See Note 2 Below)"
PTFE N/A (see PTFE fitted manual) 050.010.600 722.091.600 N/A
Aluminum N/A N/A
722.091.150
(See Note 1 Below)
720.061.608
Carbon Steel N/A N/A
722.091.080
(See Note 1 Below)
720.061.608
Stainless Steel N/A V241SS
722.091.110
(See Note 1 Below)
720.061.608
