• Model E1 Metallic Bolted
Composite repair Parts list
Air Valve Assembly
Item #
Qty.
Description
Part Number
-
1
Valve Body Assembly (Includes items 1-11)
031.V005.552
1
1
Valve Body (includes item 11)
E100A
2
1
Valve Spool Assembly (Includes items 3&4)
E100BUB ASY
3
1
Large Valve Spool U-Cup
P98-104A
4
1
Small Valve Spool U-Cup
P98-104AUB
5
1
End Cap Assembly (Includes O-Ring)
E500D ASY
6
1
Reducing End Cap Assembly (Includes O-Rings)
E500DUB ASY
7
2
Staple
E500F
8
1
CT Air Diverter
E100CT
9
1
Air Diverter Plate
E100H
10
1
Air Valve Gasket
360.V002.360
11
4
Mounting Screws
S1004
Center Section Assembly
Item #
Qty.
Description
Part Number
12
1
Center Section
E101A
13
1
Pilot Spool ASY (includes item 14)
775.V004.000
14
8
Pilot Spool O-Rings
560.023.360
15
1
Pilot Valve Sleeve ASY (includes item 16)
755.V004.000
16
6
Pilot Valve Sleeve O-Rings
560.101.360
17
2
Shaft/Pilot Retainer
670.V002.554
18
4
Retainer Screw
E101C
19
1
Muffler
VTM-4
Diaphragm Assembly / Elastomers
Item #
Qty.
Description
Part Number
TPE/RUBBER
PTFE 2-Piece
PTFE Fusion
20
2
Main Shaft O-Ring
P50-403
21
1
Main Shaft
685.V001.120
P50-108
22
2
Diaphragm
"V183xx-1
(See Below Material
Chart)"
V183TF-1
V183F
23
2
Back-Up Diaphragm
N/A
V183TB
N/A
24
2
Inner Diaphragm Plate
V181C
N/A
25
2
Outer Diaphragm Plate (See Note 1 Below)
V81B, SV181B ASY,
HV181B
SV181TO, HV181TO
N/A
26
4
Valve Seat O-Ring
"V90xx
(See Below Material
Chart)"
SV190TF
27
4
Valve Ball
"V191xx
(See Below Material
Chart)"
V191TF
Wet End Assembly
Item #
Qty.
Description
Part Number
Aluminum
Stainless Steel
Hastelloy
28
4
Valve Seat
V90A
SV190
HV190
29
2
Water Chamber
V85
SV185
HV185
30
16
Water Chamber Bolt
V187A
SV189D
31
16
Water Chamber Washer
V189C
SV189C
32
16
Water Chamber Nut
V185B
SV185B
33
1
Discharge Manifold
V86
SV186
HV186
34
1
Suction Manifold
V87
SV187
HV187
35
8
Manifold Bolt
V187A
SV187A
31
8
Manifold Washer
V189C
SV189C
32
8
Manifold Nut
V185B
SV185B
Elastomer Material Specifications
Material
Diaphragm P/N
Valve Ball P/N
O-Ring P/N
Neoprene
V183N-1
V191N
N/A
Buna Nitrile
V183BN-1
V191BN
V90BN
Viton
V183VT-1
V191VT
V90VT
Nordel
V183ND-1
V191ND
V90ND
Santoprene
V183TPEXL-1
V191TPEXL
V190XL
Hytrel
V183TPEFG
V191TPEFG
N/A
Geolast
V183G
V191G
N/A
Acetal
N/A
V191A
N/A
Stainless Steel
N/A
V191SS
N/A
Note: The outer diaphragm plate material is to match the water chamber material
