Versa-Matic 1/2 Elima-Matic Bolted Plastic (E5) - Manual (Page 12)

e5nmdlCsm-rev0314
9
• Model E5 Non-Metallic Bolted www
.
versamatic
.
com
Composite repair Parts list
Air Valve Assembly
Item # Qty. Description Part Number
- 1 Valve Body (includes items 1-11) 031.V004.552
1 1 Valve Body PE500A
2 1 Valve Spool Assembly (Includes items 3&4) E500BUB ASY
3 1 Large Valve Spool U-Cup P98-104A
4 1 Small Valve Spool U-Cup P98-104AUB
5 1 End Cap Assembly (Includes O-Ring) E500D
6 1
Reducing End Cap Assembly (Includes 560.0580.360
O-Rings)
E500DUB ASY
7 2 Staple E500F
8 1 CT Air Diverter 10-075
9 1 Air Diverter Plate E500H
10 1 Air Valve Gasket 360.V003.360
11 4 Valve Mounting Screws S1004
Center Section Assembly
Item # Qty. Description
Part Number
Polypropylene Aluminum
12 1 Center Section E501A E501A-SC
13 1 Pilot Spool ASY (Includes Item #14) 775.V003.000
14 8 Pilot Spool O-Rings 560.023.360
15 1 Pilot Valve Sleeve ASY (Includes Item #16) 755.V003.000
16 6 Pilot Valve Sleeve O-Rings 560.033.360
17 2 Shaft/Pilot Retainer 670.V001.554
18 4 Retainer Screw E501C
19 1 Muffler VTM-3
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
TPE/RUBBER PTFE 2-Piece PTFE Fusion
20 2 Main Shaft O-Ring E502B
21 1 Main Shaft E502A
22 2 Diaphragm
"E505xx
(See Below Material Chart)"
E505TF E505F
23 2 Back-Up Diaphragm N/A E505N N/A
24 2 Inner Diaphragm Plate V199C N/A
25 2 Outer Diaphragm Plate PV199B, KV199B N/A
26 4 Valve Seat O-Ring
"E510xx
(See Below Material Chart) "
E510TES
27 4 Manifold Seal N/A E510TFG
28 4 Valve Ball
"V111xx
(See Below Material Chart)"
V111SS, V111TF
Wet End Assembly
Item # Qty. Description
Part Number
Polypropylene Kynar
29 2 Water Chamber PE519 KE519
30 16 Water Chamber Bolt SV187A
31 16 Water Chamber Washer SV189C
32 16 Water Chamber Nut SV185B
33 4 Valve Ball Cage PE522 KE522
34 4 Valve Ball Seat PE521 KE521
35 1
"Discharge Manifold Assembly
(Includes Plugs)"
PE520 ASY KE520 ASY
36 1
"Suction Manifold Assembly
(Includes Plugs)"
PE520F ASY KE520F ASY
37 4 Manifold Plugs 618.058.552 P8NK
38 8 Manifold Bolts SV189D
31 8 Manifold Washer SV189C
39 8 Manifold Nut SV164D
Elastomer Material Specifications
Material Diaphragm P/N Valve Ball P/N O-Ring P/N
Neoprene E505N N/A N/A
Buna Nitrile E505BN V111BN E510BN
Viton E505VT V111VT E510VT
Nordel E505ND N/A E510TES
Santoprene E505XL V111TPEXL E510XL
Hytrel E505FG V111TPEFG E51TES
Geolast N/A V111G N/A
Acetal N/A V111A N/A
Polyurathane N/A V111PU N/A
Stainless Steel N/A V111SS N/A
MODEL SPECIFIC
3: EXP
VIEW
