#61029
2” x 4” board perpendicular to work surface.
(4) Fasteners fully embedded into side wall.
Fasteners must be ¼” x 2“ lag bolts.
#61140
(4) Fasteners fully embedded substrate.
Fasteners must be ¼” x 2“ lag bolts.
Guardrail posts and rails installed in a
manner compliant with requirements
specified by this manual.
#61141
(4) Fasteners fully embedded substrate.
Fasteners must be ¼” x 2“ lag bolts.
(2) 2” x 4” boards inserted vertically in each
Guardrail Receiver, and secured on each side with
compatible fastener.
Toeboard installed in applicable location
of Guardrail Receiver. Use compatible
fastener to hold in place.
