5 - ENG
After each use:
1. Flush the cleaning gun with warm water after each
use.
2. Place a few drops of lubricating oil at the trigger pin
(see Figure 3).
3. Put a light coating of grease on the flow valve o-ring
(see Figure 3).
4. Add two drops of mineral spirts into the barb fitting
to avoid corrosion (see Figure 3).
Always disconnect the tool from the air supply before performing any maintenance.
USER-MAINTENANCE INSTRUCTIONS USER-MAINTENANCE INSTRUCTIONS
TROUBLESHOOTING GUIDE TROUBLESHOOTING GUIDE
SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION
Tool will not siphon
properly Buildup of solution in siphon tube
Low air pressure
Air hose leaks
Flow control valve shut off
Flush with warm water.
Adjust compressor regulator to 90 PSI.
Tighten and seal hose fittings with Teflon® tape if
leaks are found.
Adjust flow control valve to desired flow.
T T OOL OOL SPECIFICA SPECIFICA TIONS TIONS
Average SCFM Requirements 5.0 SCFM @ 90 PSI
Air Inlet 1/4” NPT (male)
Siphon Hose 4 Feet
Recommended Hose Size 3/8”
Maximum Working Pressure 90 PSI
Figure 3
