19 200-2648
Item Part No Qty
Art N o / P Qté
Art Núm / P Cant Description Description Descripción
1 N/A 2 Screw, M5 X 15 ..................................Vis ...................................................Tornillo
2 077-0190 1 Parts storage lid..................................Couvercle de stockage....................Tapa del almacenaje
3 106-0045 1 Regulator plate ...................................Plat de régulateur............................Placa del regulador
4 034-0208 1 Pressure switch ..................................Interrupteur......................................Manómetro
5 141-0287 1 Manifold assembly ..............................Ensemble du collecteur...................Conjunto de múltiple
(includes items 49-56) .................................( inclut les élément 49-56) ....................( incluye los articulo 49-56)
6 N/A 24 Screw, ST4.9 x 12 ..............................Vis ...................................................Tornillo
7 112-0150 1 Handle ................................................Manette ...........................................Manija
8 N/A 6 Screw, M6 x 25 ...................................Vis ...................................................Tornillo
9 N/A 10 Nut, M6 ...............................................Écrou...............................................Tuerca
10 142-0188 1 Shroud, back.......................................Enveloppe .......................................Guardera
11 125-0181 1 Protective cover ..................................Couverture ......................................Cubierta
12 125-0180 1 Hose holder ........................................Support de tuyau.............................Sostenedor de la manguera
13 026-0775 1 Power cord..........................................Câble...............................................Cordón
14 145-0541 1 Tube, transfer w/fittings ......................Tube ................................................Tubo
15 166-0169 1 Capacitor, CBB 100µƒ 250V ..............Condensateur..................................Condensador
16 166-0168 1 Capacitor, CD60 200µƒ 250V.............Condensateur..................................Condensador
17 114-0641 1 Capacitor holder .................................Support de condensateur................Sostenedor del condensador
18 027-0043 1 Fan, motor end ...................................Ventilateur .......................................Ventilador
19 N/A 1 Circlip, 14............................................Agrafe..............................................Clip
20 ** 1 Tank....................................................Réservoir.........................................Tanque
21 125-0179 1 Base....................................................Base ................................................Base
22 095-0069 2 Wheel kit .............................................Roue................................................Rueda
23 108-0186 1 Axle.....................................................Axe ..................................................Árbol
24 072-0016 1 Petcock ...............................................Robinet de décompression .............Llave de desagüe
25 094-0133 2 Vibration pad kit ..................................Tampon ...........................................Almohadilla
26 142-0186 1 Tool compartment...............................Compartiment d'outil .......................Compartimiento de la herramienta
27 142-0187 1 Shroud, front .......................................Enveloppe .......................................Guardera
28 N/A 2 Screw, M5 x 10 ...................................Vis ...................................................Tornillo
29 N/A 4 Washer, 8 ...........................................Rondelle ..........................................Arandela
30 N/A 4 Screw, M8 x 30 ...................................Vis ...................................................Tornillo
31 031-0087 1 Check valve ........................................Clapet de retenue............................Válvula de contraflujo
32 062-0069 1 Connector, 3-way................................Connecteur......................................Conector
33 136-0091 1 Cold start valve ...................................Soupape..........................................Válvula
34 145-0542 1 Tube, transfer w/fittings ......................Tube ................................................Tubo
35 040-0394 1 Pump/motor assembly ........................Ensemble pompe/moteur ................Conjunto de bomba/motor
(includes items 18-19, 35-41 and 45-47).....( inclut les élément 18-19, 35-41 ..........( incluye los articulo 18-19, 35-41
....................................................................et 45-47) ..................................................y 45-47)
36 027-0042 1 Fan kit, pump end ...............................Kit de ventilateur .............................Kit de ventilador
37 047-0101 1 Con rod/piston assembly ....................Rod/piston trompeur........................Asamblea con de rod/piston
38 019-0253 1 Intake filter ..........................................Filtre ................................................Filtro
39 042-0124 1 Head ...................................................Tête .................................................Cabezal
40 043-0216 1 Valve plate assembly..........................Ensemble de la plaque de soupape ...Conjunto de placa de válvula
41 050-0068 1 Cylinder ..............................................Cylindre ...........................................Cilindro
42 062-0068 1 Connector, G3/8 .................................Connecteur......................................Conector
43 034-0209 1 Switch, on/off ......................................Interrupteur......................................Manómdtro
44 N/A 4 Screw, M8 x 15 ...................................Vis ...................................................Tornillo
45 N/A 2 Bolt, M6 x 80.......................................Boulon .............................................Perno
46 N/A 2 Bolt, M6 x 70.......................................Boulon .............................................Perno
47 N/A 4 Washer, spring 6.................................Rondelle ..........................................Arandela
48 N/A 4 Screw, M6 x 45 ...................................Vis ...................................................Tornillo
49 036-0031 1 Quick connect coupler .........................Raccord rapide................................Acoplador especial
50 032-0056 2 Gauge..................................................Manomètre ......................................Manómetro
51 041-0086 1 Manifold block......................................Collecteur.............................. ..........Múltiple
52 136-0077 1 Pressure relief valve ............................Soupape..........................................Válvula
53 105-0004 1 Regulator repair kit ..............................Jeu de pièces de réparation............Juego de reparación
54 055-0078 1 Spring ..................................................Ressort............................................Resorte
55 092-0032 1 Knob ....................................................Molette ............................................Perilla
56 N/A 1 Pin .......................................................Broche.............................................Contacto
N/A - These are standard parts available at your local hardware store.
N/A - Ces pièces sont des pièces standard disponibles en quincaillerie.
N/A - Estas son piezas estándares disponibles en su ferretería local.
** Items are not available as replacement parts.
** Les éléments ne sont pas disponibles comme pièces de rechange.
** Los items no están disponibles como piezas de recambio.
PARTS LIST \ LISTE DE PIÈCES \ LISTA DE LAS PIEZAS
