Poly-Tex NT3010 User Manual
Page 3
3
1. PLACE LEGS INSIDE TABLE TOPS AS SHOWN.
2. FASTEN TO TABLE TOP USING CAP SCREWS, FLAT WASHERS, LOCK
WASHERS, AND HEX NUTS.
3. REPEAT FOR ALL FOUR LEGS ON ALL THREE TABLES.
THE 24" x 30" TABLE TOP USES (4) 30" LEGS.
THE 24" x 22" TABLE TOP USES (4) 25 3/4" LEGS.
THE 22" x 14" TABLE TOP USES (4) 21 1/2" LEGS.
CAP SCREW
LOCK WASHER
FLAT WASHER
HEX NUT
