Optional caster assembly instructions, Parts identification – Poly-Tex FB3001 User Manual
Page 12
OPTIONAL CASTER ASSEMBLY INSTRUCTIONS
12
PARTS IDENTIFICATION
FB2004
SWIVEL/LOCK CASTER
(2)
THUMB
SCREW
INSTRUCTIONS:
1. REMOVE BOTTOM PLUGS.
2. INSTALL CASTER RAIL.
3. FASTEN WITH THUMB SCREWS. BE SURE CASTER STUB IS INSTALLED AS SHOWN IN ILLUSTRATION.
ONCE DISPLAY IS IN PLACE,
ALL CASTERS MUST BE
LOCKED TO PREVENT
MOVEMENT. THE BRAKE IS
ACTIVATED BY ROTATING
THE LEVER FROM THE "OFF"
POSITION TO THE "ON"
POSITION.
