www.avenview.com 10
Section 2: Specifications
Item Description
Units HDMI-C5XD-S HDMI-C5XD-SR
Unit Description
HDMI 1.3 Transmitter with Local
Output
HDMI 1.3 Transceiver with Local
Output
HDMI Compliance HDMI 1.3c
HDCP Compliance Yes
Video Bandwidth Single Link 225 MHz (6.75Gbps)
Supported Resolutions 480i / 480p / 720p / 1080i / 1080p60
Resolution and Distance
Full HD: (1080p) ~ 40meter (130feet) (CAT5e) / 50meter (165feet) (CAT6)
HD: (720p/1080i) ~ 50meter (165feet) (CAT5e) / 60meter (200feet) (CAT6)
Audio Support Surround Sound (up to 7.1 Ch) or Stereo Digital Audio
Equalization - 8 Level Digital Control
Input TMDS Signal 1.2 Volts (peak-to-peak)
Input DDC Signal 5 Volts (peak-to-peak, TTL)
ESD Protection
- Human body model — ±15kV (air-gap discharge) & ±8kV (contact discharge)
- Core chipset — ±8kV
Input 1 x HDMI 1 x RJ45
Output
1 x HDMI
1 x Rj45
1 x 3.5mm Audio
1 x HDMI
1 x RJ45
1 x 3.5mm Audio
HDMI Connector Type A (19 pin female)
RJ45 Connector WE/SS 8P8C with 2 LED indicators
Audio Connector 3.5mm
DIP Switch Yes -
Dimensions (L x W x H) 4.3” x 8.3” x 1.1”
Power Supply 5V 4A DC
Power Consumption 3 Watt (max)
Environmental
Operating Temperature 32˚ ~ 104˚F (0˚ to 40˚C)
Storage Tempearture -4˚ ~ 140˚F (-20˚ ~ 60˚C)
Relative Humidity 20~90% RH (no condensation)
