PAASCHE® VLSTPRO Airbrush Components
Page 2
NO. PART NO. DESCRIPTION
1. XI-41 Needle Protecting Cap
2. VLH-1, 3 or 5 Head (Sizes 1 & 5 Optional)
3. VLT-1, 3 or 5 Tip (Sizes 1 & 5 Optional)
5. VLS-163 ‘VLS’ Shell Assembly w/ VL-20
6. MU-612 PTFE Packing & Packing Nut (sold
as set)
7. VL-175 Line Adjustment Assembly
8. VL-213 Trigger
9. VL-186 Needle Valve Assembly
10. VL-191A Rocker Assembly
11. VL-140 Spring
12. VL-136A Needle Adjusting Sleeve
13. VL-141 Locknut
NO. PART NO. DESCRIPTION
14. VL-134C Cut-Away Handle (w/ ‘O’ Ring VL-224)
15. VL-215 Air Valve Assembly
16. VL-20 Valve Casing
18. VL-214 Valve Plunger (with A-53)
19. A-22 Valve Spring
20. A-23R Air Valve Nut
21-23. VLN-1, 3 or 5 Needle (Sizes 1 & 5 Optional)
Optional Items:
17. A-53 Valve ‘O’ Ring (Pack of 6)
24. VL-54 Reamer (Optional)
14a. VL-224 ‘O’ Ring for VL-134C
VL-227-1, 3 or 5 Multiplehead (Specity Size)
VLH-1, 3 or 5 Head
VLT-1, 3 or 5 TIP
VLN-1, 3 or 5 Needle
VLSTPRO AIRBRUSH PARTS
