Paasche M I L L E N N I U M Double Action Airbrush – Internal Mix Page 4
NO.PART NO. DESCRIPTION
1. VL-1/4-OZ Metal Color Cup (7cc)
2. VL-1/2-OZ Color Bottle Assembly (14.5cc)
VL1/2 1/2 oz. Cover Assembly
VF-17 Color Tube
3. VL-1-OZ Color Bottle Assembly (29cc)
VL1 1 oz. Cover Assembly
VF-17 Color Tube
5-G Gasket
4. VL-3-OZ Color Bottle Assembly (88cc)
VL3 3 oz. Cover Assembly
VF-14 Color Tube
3-JG Gasket
5. PCVL-3-OZ Nylon Cover/Metal Tube Bottle
Assembly (88cc)
PCVL3 Nylon Cover Assembly
VF-14M Metal Color Tube
3-JG Gasket
6. VLP-3-OZ Plastic Bottle Assembly (88cc)
VL3 3 oz. Cover Assembly
VF-14 Color Tube
3-JG Gasket
7. VL-2-OZ Aluminum Cup Assembly (60cc)
VF-2-5/8 Color Tube
3-JG Gasket
8. VLD-3-OZ Decorator Bottle Assembly (88cc)
VLD3 3 oz. Cover Assembly
VF-14 Color Tube
3-JG Gasket
MILLENNIUM ACCESSORIES
MILLENNIUM CUP AND BOTTLE ASSEMBLIES
NO.PART NO. DESCRIPTION
9. VL-127 Strainer for PTFE White Color Tubes Only
10. A-34 Hanger
11. V-62 Wrench
12. MT Moisture Trap (Do-It-Yourself Installation)
13. HP-1/8 PVC Red Plastic Airhose w/cplgs.
14. A-1/8 Braided Airhose w/Couplings
15. AC-20 1/8"-1/4"-40 Coupling (To Airbrush)
16. AC-1/8 -1/4" Coupling (To Compressor)
PART NO. DESCRIPTION
F-143 Red Plastic Handle
R-75 Reg. & Filter w/Gauge
VL-54 Reamer
D500 Air Compressor (115v.,60cyl.)
HSSB-22-16 Hobby-Shop Spray Booth
PP-1, 3 or 5 Paint Picker Aircap for easy removal of
dried paint. Match to Tip.
A-194 Deluxe Airbrush Hanger
Accessories not shown
D500 AIR COMPRESSOR (1/8 H.P.) (ETL Listed)
Economical and suitable for all airbrushes spraying properly
thinned fluids. It is capable of delivering up to 35 P.S.I.
operating pressure depending on airbrush being used. The
Paasche D500 is an oilless piston compressor. It operates on
110-120 Volt, 1 phase, 60Hz, and delivers .4 C.F.M. @ 20
P.S.I.
Shipping Weight: 8 lbs. (3.6kg)
D220R AIR COMPRESSOR (1/6 H.P.), with Switch
& R-75 Regulator
Economical and suitable for all airbrushes spraying
properly thinned fluids. It is capable of delivering 30 -
45 P.S.I. operating pressure depending on airbrush
being used. The Paasche D220R is an oilless
diaphragm unit and comes with the R-75
Regulator/Filter with gauge. It operates on 110-120
Volt, 1 phase, 60Hz, and delivers .7 C.F.M. @ 20
P.S.I. R75 Regulator will regulate up to 45 P.S.I.
depending on usage (intermittent or constant) and
size of airbrush being used.
Shipping Weight: 11 lbs. (5kg)
DA300R AIR COMPRESSOR (1/6 H.P.)
with Switch CSA approved & R-75 Regulator
1/8 H.P. Piston Compressor with Auto shutoff.
Compressor shuts off when airbrush is not in use.
Operating pressure is 20 - 30 P.S.I. depending on
airbrush being used, delivers up to 35 psi. 120 VAC, 1
Ph, 60 Hz, 1.4 A, 20L/Min. (0.7CFM), Noise 53dB,
1720 rpm.
Shipping Weight: 9.14 lbs. (4.6 kgs)
DA400R AIR COMPRESSOR (1/6 H.P.)
1/6 H.P. Piston Compressor with Auto shutoff.
Compressor shuts off when airbrush is not in use.
Operating pressure 30 - 50 PSI depending on
airbrush being used, delivers up to 55 psi.. 110-
120VAC, 1 Ph, 60 Hz, 42L/Min. (1.48CFM), 1720 rpm.
With R-75 Regulator & Moisture Trap included.
Shipping Weight: 12.2 lbs. (5.6 kgs)
Recommended Compressors and Acessories
