Master Manufacturing Economy ATV Sprayer - Manual (Page 5)

Master Manufacturing
Econo ATV Sprayer
Item # Part Number Description Qty.
1 31-100285 Bracket, Mount, Stick Boom 1
2 GC-100-KIT Clip, Gun (Pair), Includes Screws 1
3 33-100427 Nut, ¼-20, Self Retaining 1
4 TS-T-1/4-10-1.25 Screw, Thumb, “T”, 1/4 X 1.25” 1
5 31-100286 Bracket, Lock, Stick Boom 1
6 31-100284 Boom, Stick, No Nozzle 1
7 BN-2BBP125FWX Nozzle, No-Boom BP, 152 Full 1
8 3NTL1238 ELB.NZTHD:11/16`MPSx3/8`HB 1
9 3NF1614 Coupling: 11/16”FPS X 1/4"FPT 1
10 SHC-E Snapper Hose Clips, BLK 3
11 EF2200 Pump, 2.2GPM EVERFLO 1
12 33-103231 Tank, 15 Gal, Sprayer 1
13 33-100138 10-24 NUT 2
14 3A38 Straight: 3/8” MPT X 3/8” HB Poly 1
15 RCH-14-15 Hose, Recoil, 1/4` DIA, 1
16 SG-4507F Gun, Wand Spry, W/Filter, w/nozzle 1
17 SG-45ASSY-18 Nozzle 1
18 33-100164 Strap, Ratchet, 1’ X 10’, 1200LBS 2
19 33-100176 Gasket, Nozzle 1
20 33-103126 Screw, Machine, 10-24 X 5/8” 4
21 33-103131 Washer, #10, Zinc 4
22 33-103121 Strainer, Inlet, 3/8” HB, SS 1
23 PBV-38HB12 Valve, ½” MNPT x 3/8” hose barb 4
24 3EL1214 Elbow, ½” MNPT x ¼” hose barb 1
25 3TT12 Tee, ½” MNPT 1
26 M1238 Adaptor, ½” MNPT x 3/8” MNPT 1
27 33-103218 Outlet Cap, 3/4` Black 1
28 33-103221 LID, 5`W .25` Hole 1
29 33-103220 Gasket, 3/4” SuperSeal 1
30 33-103233 Harness, Wire, Switched. 10ft 1
31 SHC-BB Snapper Hose Clip, Min=.362, Max=.426 2
32 33-103938 Tube, Vinyl Braid, .37x.59
Inlet hose .37”x 18”, Boom hose .37” x 14”
2
