Figure #3
Axel, Hitch and Wheel Assembly
Item No. Part Number Description Qty.
1 32-100063 Mount, Boom 1
2 33-100116 Screw, cap, 5/16-18 x 1” 11
3 33-100115 Washer, 5/16 4
4 33-100113 Nut, 5/16-18, serrated 11
5 TWA-18X7-8/4HOLE Tire and Wheel Assembly, 60 Gallon 2
TWA-15X600-6 Tire and Wheel Assembly, 40 Gallon 2
6 33-100125 Nut, 3/8-16” 2
7 32-100066 Hitch, Adjustable 1
8 33-100124 Cap screw, 3/8-16 x 1” 2
9 32-100067 Tongue, Hitch 1
10 34-140048 Axel, Heavy duty, 60 Gallon 1
32-100062 Axel, 40 Gallon 1
11 33-100127 Cotter Pin, 40 Gallon only 2
