Parts list – American Dryer Corp. SL2929 User Manual
Page 7
450379-1
www.amdry.com
7
Illus. No.
Part No.
Qty.
Description
DETAIL 3
34
143025
1
3/8” x 3/4” N.P.T. Nylon Hose Adaptor
35
143155
3
3/8” Brass Street Elbow
36
143241
2
3/8” Close Nipple
37
136987
1
Water Pressure Switch
38
319231
2
S.A.F.E. Valve Bracket
165120
1
S.A.F.E. Valve 24V DC
39
143182
1
3/4” x 3/8” x1/8” Tee
40
318422
2
S.A.F.E. Nozzle Bracket
41
143251
1
3/8” Brass Plug
42
143208
2
3/8” Connector
43
150331
2
#8-18 x 1/2” T20 TORX
44
143581
2
S.A.F.E. 3/8” N.P.T. Spray Nozzle
819337
1
Phase 8 Deltrol S.A.F.E. Assembly
143236
1
3/8” Brass Pipe Cross
143099
1
3/8” Copper Tubing
DETAIL 4
45
185023
2
Gas Pipe Bracket
46
154356
2
U-Bolt with Nuts
47
185179
2
Hot Surface Ignition Gas Pipe
143003
1
Coupling
143026
1
5” Nipple
48
130500
2
Radiant Control Sensor
49
183145
2
#8-32 x 7/8” Hex Conical
50
318979
2
Gas Train Support Bracket
51*
140875
2
#26 Burner Orifice (Natural Gas)
140881
2
#47 Burner Orifice (Liquid Propane Gas)
52
185061
2
Hot Surface Ignition Burner Base
53
143318
2
Brass Adaptor
54
128944
2
25m Gas Valve 120 VAC 60 Hz
128907
2
120V Valve 50 Hz
*
884334
2
‘M’ Valve 80k Btu Liquid Propane Kit
55
183144
2
Inshot Burner Tube Hot Surface Ignition
56
185063
2
Hot Surface Ignition Ignitor Bracket
57
128910
2
Hot Surface Ignitor 80V
58
819600
2
Thermostat Assembly
59
150331
16
#8-18 x 1/2” T20 TORX
60
185066
2
Burner Cone
319281
2
Burner Cone Sleeve
819437
2
120V 60 Hz Gas Train Assembly
819813
2
230V 50 Hz Gas Train Assembly
132029
2
350VA Autotransformer (208-240)
DETAIL 5
61
819347
2
Lint Box Top Stud Assembly
62
130112
2
Thermostat 225º Automatic
63
122002
2
Lint Door Switch
64
818804
2
Lint Coop Blower Assembly
65
318866
2
4 Circuit Connection Plate
66
150331
2
#8-18 x 1/2” T20 TORX
67
318224
2
Blower Housing Rear Support Bracket
68
818725
2
Blower Housing
(for models mfd. prior to April 2006)
185139
2
Blower Housing
(for models mfd. as of April 2006)
319904
2
Blower Housing Mount
(for models mfd. as of April 2006)
818975
2
120V Blower Motor Assembly
819277
2
230V Blower Motor Assembly (Phase 8)
319144
2
Exhaust Extension
69
153049
4
Washer
70
153024
4
#10 Split Lock Washer
71
152008
8
#10-32 Hex Nut
72
100623
2
25 MFD Capacitor 120 VAC 50-60 Hz
100633
2
6 MFD Capacitor 230 VAC 50-60 Hz
73
117604
20
1/8” Thick x 3/8” Wide Neoprene Sponge Tape
74
818803
2
Lint Box Assembly
75
818986
2
Phase 8 Exhaust Temperature Sensor Assembly
76
154007
4
1/4” Push-On Fastener
77
117604
2
1/8” Thick x 3/8” Wide Neoprene Sponge Tape
*
Contact factory for elevations above 2,000 feet.
