IEI Integration ITDB-100L - Manual (Page 73)

ITDB-100L Barcode Reader
Page 64
key on the Android device to return to the barcode reader list screen. Then the
automatic setting parameters will be stored to the barcode reader.
Step 4: When the automatic setting is failed, the message
will appear, and the atutomatic setting process will stop. Then all the parameters
will be restored to the last-saved settings.
6.5.6.2 LED Brightness
The (LED brightness) option allows the user to adjust the LED brightness.
Step 1: Tap , then drag the slider at the bottom of the screen (Figure 6-6) to adjust
the percentage of the LED brightness.
Figure 6-6: Percentage of LED Brightness
Step 2: Tap or the Back key on the Android device to return to the barcode reader
list screen. Then the brightness parameter will be stored to the barcode reader.
