IEI Integration MPCIE-USB3 - Manual (Page 2)

2
Features:
1. Supporting two external USB 3.0 type A ports
2. USB 3.0 provides up to 5Gbps of transferring rate
3. Backward compatible with USB 2.0 and USB 1.0/1.1 devices
4. Fully compliant with USB 3.0 rev 1.0 specifications and Intel xHCI
rev 0.96 specifications, with transfer rates up to 5Gbps
5. Compliant with PCI Express Mini Card specification 1.2
Specification:
USB 3.0 Controller IC: Asmedia ASM1042
USB 3.0 Internal Connector: 1 x 20-pin (2x10) box header
Power Jack: 1 x 4-pin box header
Compatible OS: Windows 2000/ XP/ Server 2003/ Server 2008/
Vista/ 7
Linux kernel version 2.6.32 above
Operating Temperature: -10°C ~ 60°C
Operating Humidity: 5% ~95%, non-condensing
Diemension (LxW): 50mm x 30mm
Weight: 70g
Ordering Information:
MPCIE-USB3-R10:
Mini PCI Express USB 3.0 adapter card, RoHs
19800-010500-100-RS: Dual USB 3.0 type A ports cable with bracket
