IEI Integration DP-VGA - Manual (Page 3)

3
Table of Connectors
CN1 : iEi Internal Display Port
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +5V 2 DPD_OB_LANE1_N
3 DPD_OB_LANE1_P 4 GND
5 DPD_OB_LANE3_N 6 DPD_OB_LANE3_P
7 GND 8 AUX_CTRL_DET_D
9 GND 10 DDI1_HPD#
11 DPD_AUX_CTRL_P2 12 DPD_AUX_CTRL_N2
13 GND 14 DPD_OB_LANE2_P
15 DPD_OB_LANE2_N 16 GND
17 DPD_OB_LANE0_P 18 DPD_OB_LANE0_N
19 +3.3V
19 17 15 13 11 9 7 5 3 1
● ● ● ● ● ● ● ● ● ■
● ● ● ● ● ● ● ● ●
20 18 16 14 12 10 8 6 4 2
