Burner Dia. Tap By-pass Tap colour
1/100 mm
Auxiliary 28 Red/Red
Semi-rapid 32 Blue/Blue
Rapid 40 Black/Black
Aeration adjustment none
BURNER RAPID SEMI-RAPID AUXILIARY
(large) (medium) (small)
POSITION MAX MIN MAX MIN MAX MIN
NOMINAL THERMAL
POWER kW
3.0 0.65 2.0 0.45 1.0 0.33
NOMINAL FLOW
RATE m
3 /h 0.286 0.057 0.190 0.038 0.095 0.028
NOZZLE REFERENCE 119 Adjust. 96 Adjust. 70 Adjust.
1/100 mm
NOMINAL THERMAL
POWER kW
2.8 0.65 2.0 0.45 1.0 0.33
NOMINAL FLOW
RATE g/h
202 43.5 144 29 72 21,5
NOZZLE REFERENCE 86 40 71 32 50 28
1/100 mm
NATURAL GAS
20 mbar
VALUE =
37.78 MJ/m 3
Ws - 50.7 MJ/ m 3
TYPE OF GAS
LPG GAS
28-30/37 mbar
VALUE =
49.92 MJ/Kg
