IMBA-Q670 ATX Motherboard
Page 8
Specification/Model IMBA-Q670
Display port One VGA Integrated in the Intel® Q67
One HDMI Integrated in the Intel® Q67
One DVI-D Integrated in the Intel® Q67
Ethernet Two RJ-45 GbE ports
Keyboard/Mouse Dual PS/2 port
One internal keyboard and mouse connector via 6-pin wafer
TPM One via 20-pin header
Serial Ports One external RS-232 serial port
Four RS-232 via internal box headers
One RS-422/485 via internal 4-pin wafer
Parallel Port One parallel port via internal 26-pin box header
USB ports Two external USB 3.0 ports on rear IO by NEC D720200F1
Two external USB 2.0 ports on rear IO
Eight internal USB 2.0 ports by four pin headers
Serial ATA Four SATA 3Gb/s channels with 3Gb/s data transfer rates
Two SATA 6Gb/s channels with 6Gb/s data transfer rates
Environmental and Power Specifications
Power Supply ATX power supported
Power Consumption [email protected], [email protected] , [email protected], [email protected], [email protected]
(3.10 GHz Intel® Core™ i5 2400 CPU with four 1333 MHz 4GB
DDR3 memory)
Operating temperature -10ºC ~ 60ºC
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 244 mm x 305 mm
Weight GW/NW 1200 g / 700 g
Table 1-1: IMBA-Q670 Specifications
