12
Type
E QU131
EQU215
EQU2215
EQU131VU
EQU231VU / 231LED 2 15 Band: 2/3 octave , ISO spacing (1H series)
2 15 Band: 2/3 octave , ISO spacing (2H series)
1 31 Band: 1/3 octave , ISO spacing (1H series)
2 31 Band: 1/3 octave , ISO spacing (2H series)
6. TECHNICAL SPECIFICATIONS
Slider travel 20mm with positive centre detente
(EQU131/EQU215/EQU231VU/EQU231LED)
60mm with positive centre detente
(EQU131VU/EQU2215/EQU231TWIN)
6dB or 12dB selectable
Active balanced XLR and 1/4" TRS
Unbalanced RCA
20k (bal.)
15k (unbal.)
18dBv
Active balanced XLR and 1/4" TRS
Unbalanced RCA
600
16dBv
>10K
40Hz (12dB/oct) fixed-button type .
16KHz (12dB/oct) fixed-button type
20Hz to 50KHz at - 3dB
0.02% (@ 1KHz , all VR at middle position)
93dB (@ 1KHz )
110V-120VAC -60Hz
220V-240VAC -50Hz
1 31 band, 1/3 octave, ISO spacing: 7W
2 15 band, 2/3 octave, ISO spacing: 9W
2 31 band, 1/3 octave, ISO spacing: 12.5W
483(W) 220(D) 44(H)(19" 8.66" 1.7")mm (1H series)
483(W) 220(D) 88(H)(19" 8.66" 3.5") mm (2H series)
483(W) 220(D) 177.8(H)(19" 8.66" 7") mm (4H series)
Range
Input connections
Output connections
Input impedance
Maximum input level
Output impedance
Maximum output level
Load impedance
High pass filter
Low pass filter
Frequency response
THD + N %
S / N ratio
Power supply
Consumption
Dimensions
EQU131/131VU
EQU215/2215
EQU231VU / 231LED/231TWIN
1 31 Band: 1/3 octave , ISO spacing (2H series)
EQU231TWIN 2 31 Band: 1/3 octave , ISO spacing (4H series)
